LTC3114MPFE-1 ADI IC REG BCK BST ADJ 1A 16TSSOP
LTC3114MPFE-1 Images
LTC3114MPFE-1 Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators Package/Case: 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
  • Description: IC REG BCK BST ADJ 1A 16TSSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
LTC3114MPFE-1 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
LTC3114MPFE-1 Specifications:
  • MfrPart.: LTC3114MPFE-1#PBF
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: IC REG BCK BST ADJ 1A 16TSSOP
  • Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • Function: Step-Up/Step-Down
  • OutputConfiguration: Positive
  • Topology: Buck-Boost
  • OutputType: Adjustable
  • NumberofOutputs: 1
  • Voltage-Input(Min): 2.2V
  • Voltage-Input(Max): 40V
  • Voltage-Output(Min/Fixed): 2.7V
  • Voltage-Output(Max): 40V
  • Current-Output: 1A
  • Frequency-Switching: 1.2MHz
  • SynchronousRectifier: Yes
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
  • LTC3114MPFE-1 Analog Devices (ADI), IC REG BCK BST ADJ 1A 16TSSOP, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
LTC3114MPFE-1, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
