LTC3523EUD Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators Package/Case: 16-WFQFN Exposed Pad
- Description: IC REG BUCK BST ADJ DL 16QFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LTC3523EUD Specifications:
- MfrPart.: LTC3523EUD#PBF
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC REG BUCK BST ADJ DL 16QFN
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
- Package: Tube
- Series: -
- PartStatus: Active
- Function: Step-Up, Step-Down
- OutputConfiguration: Positive
- Topology: Buck, Boost
- OutputType: Adjustable
- NumberofOutputs: 2
- Voltage-Input(Min): 1.8V
- Voltage-Input(Max): 5.5V
- Voltage-Output(Min/Fixed): 0.615V
- Voltage-Output(Max): 5.5V
- Current-Output: 400mA, 600mA (Switch)
- Frequency-Switching: 1.2MHz
- SynchronousRectifier: Yes
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-WFQFN Exposed Pad
- LTC3523EUD Analog Devices (ADI), IC REG BUCK BST ADJ DL 16QFN, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
LTC3523EUD, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
