LTC3805IMSE Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width) Exposed Pad
- Description: IC REG CTRLR FLYBACK 10MSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LTC3805IMSE Specifications:
- MfrPart.: LTC3805IMSE#PBF
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC REG CTRLR FLYBACK 10MSOP
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
- Package: Tube
- Series: -
- PartStatus: Active
- OutputType: Transistor Driver
- Function: Step-Up/Step-Down
- OutputConfiguration: Positive, Isolation Capable
- Topology: Flyback
- NumberofOutputs: 1
- OutputPhases: 1
- Voltage-Supply(Vcc/Vdd): 3.95V ~ 9.5V
- Frequency-Switching: 70kHz ~ 700kHz
- DutyCycle(Max): 80%
- SynchronousRectifier: No
- ClockSync: Yes
- SerialInterfaces: -
- ControlFeatures: Enable, Soft Start
- OperatingTemperature: -40°C ~ 125°C (TJ)
- MountingType: Surface Mount
- Package/Case: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width) Exposed Pad
- LTC3805IMSE Analog Devices (ADI), IC REG CTRLR FLYBACK 10MSOP, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
LTC3805IMSE, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
