LTC7813IUH ADI IC REG CTRLR BUCK/BOOST 32QFN
LTC7813IUH Images
LTC7813IUH Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 32-WFQFN Exposed Pad
  • Description: IC REG CTRLR BUCK/BOOST 32QFN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
LTC7813IUH Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
LTC7813IUH Specifications:
  • MfrPart.: LTC7813IUH#PBF
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: IC REG CTRLR BUCK/BOOST 32QFN
  • Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • OutputType: Transistor Driver
  • Function: Step-Up, Step-Down
  • OutputConfiguration: Positive
  • Topology: Buck, Boost
  • NumberofOutputs: 2
  • OutputPhases: 1
  • Voltage-Supply(Vcc/Vdd): 4.5V ~ 60V
  • Frequency-Switching: 105kHz ~ 835kHz, 350kHz ~ 535kHz
  • DutyCycle(Max): 96%, 99%
  • SynchronousRectifier: Yes
  • ClockSync: No
  • SerialInterfaces: -
  • ControlFeatures: Enable, Frequency Control, Power Good, Soft Start, Tracking
  • OperatingTemperature: -40°C ~ 125°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 32-WFQFN Exposed Pad
  • LTC7813IUH Analog Devices (ADI), IC REG CTRLR BUCK/BOOST 32QFN, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
LTC7813IUH, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
