MUX24EQ ADI DUAL 4-CH ANALOG MULTIPLEXER
MUX24EQ Images
MUX24EQ Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-CDIP (0.300, 7.62mm)
  • Description: DUAL 4-CH ANALOG MULTIPLEXER
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MUX24EQ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
MUX24EQ Specifications:
  • MfrPart.: MUX24EQ
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: DUAL 4-CH ANALOG MULTIPLEXER
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SP4T
  • Multiplexer/DemultiplexerCircuit: 4:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 300Ohm
  • Channel-to-ChannelMatching(ΔRon): 45Ohm
  • Voltage-SupplySingle(V+): ±15V
  • Voltage-SupplyDual(V±): ±15V
  • SwitchTime(TonToff)(Max): 2µs, 500ns
  • -3dbBandwidth: -
  • ChargeInjection: -
  • ChannelCapacitance(CS(off)CD(off)): 2.5pF, 7pF
  • Current-Leakage(IS(off))(Max): 1nA
  • Crosstalk: -70dB @ 500kHz
  • OperatingTemperature: -25°C ~ 85°C
  • MountingType: Through Hole
  • Package/Case: 16-CDIP (0.300, 7.62mm)
  • MUX24EQ Analog Devices (ADI), DUAL 4-CH ANALOG MULTIPLEXER, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MUX24EQ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
