MUX24FS Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: DUAL 4-CH ANALOG MULTIPLEXER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MUX24FS Specifications:
- MfrPart.: MUX24FS
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: DUAL 4-CH ANALOG MULTIPLEXER
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 400Ohm
- Channel-to-ChannelMatching(ΔRon): 80Ohm
- Voltage-SupplySingle(V+): ±15V
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 2µs, 600ns
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 2.5pF, 7pF
- Current-Leakage(IS(off))(Max): 2nA
- Crosstalk: -70dB @ 500kHz
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- MUX24FS Analog Devices (ADI), DUAL 4-CH ANALOG MULTIPLEXER, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MUX24FS, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
