SW06BQ/883C Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-CDIP (0.300, 7.62mm)
- Description: QUAD SPST JFET ANALOG SWITCH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SW06BQ/883C Specifications:
- MfrPart.: SW06BQ/883C
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: QUAD SPST JFET ANALOG SWITCH
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO/NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 150Ohm
- Channel-to-ChannelMatching(ΔRon): 30Ohm
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 700ns, 500ns
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 7pF, 5.5pF
- Current-Leakage(IS(off))(Max): 60nA
- Crosstalk: -70dB @ 500kHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Through Hole
- Package/Case: 16-CDIP (0.300, 7.62mm)
- SW06BQ/883C Analog Devices (ADI), QUAD SPST JFET ANALOG SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
SW06BQ/883C, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
