SW7510BQ/883C ADI QUAD SPST JFET SWITCH
SW7510BQ/883C Images
SW7510BQ/883C Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-CDIP
  • Description: QUAD SPST JFET SWITCH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SW7510BQ/883C Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
SW7510BQ/883C Specifications:
  • MfrPart.: SW7510BQ/883C
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: QUAD SPST JFET SWITCH
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SPST - NO
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 100Ohm
  • Channel-to-ChannelMatching(ΔRon): 15Ohm
  • Voltage-SupplySingle(V+): 36V
  • Voltage-SupplyDual(V±): 36V
  • SwitchTime(TonToff)(Max): 550ns, 450ns
  • -3dbBandwidth: -
  • ChargeInjection: -
  • ChannelCapacitance(CS(off)CD(off)): 6.5pF, 6.5pF
  • Current-Leakage(IS(off))(Max): 3nA
  • Crosstalk: 60dB @ 100kHz
  • OperatingTemperature: -55°C ~ 125°C
  • MountingType: Through Hole
  • Package/Case: 16-CDIP
  • SW7510BQ/883C Analog Devices (ADI), QUAD SPST JFET SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
SW7510BQ/883C, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
